USE-60P Ultrasonic Soldering Iron

USE-60P Ultrasonic Soldering Iron

$3,199.00
$3,199.00 $3,199.00
Sale Sold out
Shipping calculated at checkout.
View full details

OUR SERVICES

Shipping

  • Orders are typically processed & shipped within 2-7 business day.
  • Delivery Time:5-35working days to North America and other countries
  • Delivery Time:7-35working days to Europe
  • Shipping to North America and other countries $119.00 USD
  • Shipping to Europe $129.00 USD
Learn more

Returns

  • Accept 30 days for return
  • Customer provides return shipping costs
  • No return fees
  • Please note: The item must be unused, and in it's original packaging.
  • Please write “RETURNED ITEM” on the packaging.
Learn more

Let's get into the nitty gritty details.

Describe

The ultrasonic soldering iron consists of a high performance sheath heater and transducer, supplying heat and ultrasonic oscillations to the tip. The ultrasonic soldering is implemented by the cavitation effect which breaks the oxide surface and eliminates bubbles in solder. Using the solder alloy, can easily solder directly to glass, ceramics and other low solderability materials. It has been widely used in soldering solar cell, LED, ITO glass etc.

  • No surface pre-treatment required
  • No flux, therefore, no post cleaning
  • Gas-tight and heat-resistant up to 250°C
  • Solder materials: glass, ceramics, aluminum, steel etc
  • Stronger non-porous bonds between solder and material
  • Compressed air for cooling the transducer

Feature

Advantage of soldering hand tool with hot gas stream compare to the standard soldering tool:

  • Cooling of the Vibrator Unit in the Soldering Tool
    Long continuous usage with maximum ultrasonic-power heats up the piezo vibrator unit in the soldering tool to unaccepted high values. With the use of a cooling air stram, the tempetature of the piezo vibrator unit can be held the critical temperature. This allows a non-stop continuous operation.
  • Air stream can be adjusted from 0-25 ltr/min

Generator Parameter

  • Ultrasonic frequency: 60kHz±5kHz, automatically follow to resonance frequency
  • Ultrasonic power: 15W(max)
  • Power requirements: AC100V/240V, 50/60Hz
  • Temperature control: PID， measure resistance integrated in the heating element.
  • Temperature range: 150-500℃
  • Heater: 80watt
  • Monitor: Touch screen: Show the power, temperature and Amplitude.
  • Dimensions: 206mm(L)*310mm(W)*264mm(H)
  • Weight: 8kg

Iron Parameter

  • Transducer: (P.Z.T.) 60kHz
  • Tip material: Special steel alloy
  • Tip diameter: Φ1.0-4.0mm (custom made)
  • Heater: High performance sheathed heater 80W
  • Tip shape: Custom availble
  • Dimensions: Φ36mm(max)*250mm
  • Weight: 210g
  • Diameter of tube air hose: 4mm.
  • Cooling: Yes

Package Including

  • Ultrasonic generator x 1
  • Soldering iron tip x 1
  • Power cord x1
  • Foot Switch x1
  • Soldering iron stand x1
  • Fuse x2
  • Spanner for changing tip x1
  • A sample package of active solder alloy
  • Users manual (USE-60P)
