USE-40P Ultrasonic Soldering Iron

The ultrasonic soldering iron consists of a high performance sheath heater and transducer, supplying heat and ultrasonic oscillations to the tip. The ultrasonic soldering is implemented by the cavitation effect which breaks the oxide surface and eliminates bubbles in solder. Using the solder alloy, can easily solder directly to glass, ceramics and other low solderability materials. It has been widely used in solar cell, ITO glass,target material etc fields.

• No surface pre-treatment required
• No flux, therefore, no post cleaning
• Gas-tight and heat-resistant up to 250°C
• Solder materials: glass, ceramics, aluminum, steel etc
• Stronger non-porous bonds between solder and material
• Compressed air for cooling the transducer


Advantage of soldering hand tool with hot gas stream compare to the standard soldering tool:

• Cooling of the Vibrator Unit in the Soldering Tool
  Long continuous usage with maximum ultrasonic-power heats up the piezo vibrator unit in the soldering tool to unaccepted high values. With the use of a cooling air stram, the tempetature of the piezo vibrator unit can be held the critical temperature. This allows a non-stop continuous operation.
• Air stream can be adjusted from 0-25 ltr/min

• Ultrasonic frequency: 40kHz±5kHz
• Ultrasonic power: 20W(max)
• Max temperature: 500℃
• Display: Amplitude, Power, Set temperature, Current temperature
• Dimensions: 206mm(L)*310mm(W)*264mm(H)
• Weight: 8kg

• Transducer: Langevin type (P.Z.T.) 40kHz
• Tip material: Special steel alloy
• Tip diameter: Φ5.0-12.0mm (custom made)
• Heater: High performance sheathed heater 150W
• Tip shape: Custom availble
• Dimensions: Φ40mm*329mm
• Weight: 450g
• Diameter of tube air hose: 4mm.
• Cooling: Yes
• Without Power cord

• Ultrasonic generator x 1
• Soldering iron tip x 1
• Power cord x1
• Foot Switch x1
• Soldering iron stand x1
• Fuse x2
• Spanner for changing tip x1
• A sample package of active solder alloy
• Users manual (USE-40P)
